High Tensile Sheet

High Tensile Sheet

High Tensile Sheet is a specially engineered steel product known for its exceptional strength, durability, and resistance to deformation under stress. Manufactured using advanced rolling and heat treatment processes, it offers a superior strength-to-weight ratio, making it ideal for demanding industrial applications. High tensile sheets are designed to withstand high loads while reducing overall material weight, contributing to improved performance and cost-efficiency in various structural and mechanical uses.

At Kaustubh Enterprises, we supply high-quality high tensile sheets in various grades and thicknesses to suit the specific needs of our clients. These sheets are widely used across sectors such as automotive, construction, heavy engineering, and infrastructure development. With excellent weldability, formability, and surface finish, our products are engineered to deliver consistent performance, ensuring reliability and strength in every application.

HSLA340 Chemical Composition
Element Maximum (%)
Carbon (C) ≤ 0.12
Manganese (Mn) ≤ 1.60
Phosphorus (P) ≤ 0.035
Sulfur (S) ≤ 0.035
Niobium (Nb) ≤ 0.05
Vanadium (V) ≤ 0.10
Iron (Fe) Balance
HSLA340 Mechanical Properties
Property Typical Value Unit
Yield Strength ≥ 340 MPa
Tensile Strength 450 – 560 MPa
Elongation ≥ 20 %
Impact Toughness High (as per spec) -
HSLA420 Chemical Composition
Element Max (%)
Carbon (C) 0.12
Manganese (Mn) 1.60
Phosphorus (P) 0.030
Sulfur (S) 0.030
Niobium (Nb) 0.05
Vanadium (V) 0.10
Iron (Fe) Balance
HSLA420 Mechanical Properties
Property Value Unit
Yield Strength ≥ 420 MPa
Tensile Strength 480 – 620 MPa
Elongation ≥ 18 %
Impact Toughness High (as per spec) -
BSK-46 Chemical Composition
Element Typical Range (%)
Aluminum (Al) Balance
Silicon (Si) 10.0 – 13.0
Copper (Cu) 3.0 – 5.0
Magnesium (Mg) 0.1 – 0.5
Iron (Fe) ≤ 1.0
Nickel (Ni) 0.5 – 1.0
Zinc (Zn) ≤ 1.0
Others ≤ 0.5
BSK-46 Mechanical Properties
Property Typical Value Unit
Tensile Strength 210 – 300 MPa
Yield Strength 140 – 200 MPa
Elongation 2 – 4 %
Hardness 80 – 120 HB
Density 2.7 g/cm³
HSLA 460 Chemical Composition
Element Typical Range (%)
Carbon (C) ≤ 0.20
Manganese (Mn) 1.00 – 1.70
Phosphorus (P) ≤ 0.025
Sulfur (S) ≤ 0.020
Silicon (Si) ≤ 0.60
Niobium (Nb) ≤ 0.05
Vanadium (V) ≤ 0.10
Titanium (Ti) ≤ 0.03
HSLA 460 Mechanical Properties
Property Value Unit
Yield Strength (min) 460 MPa
Tensile Strength 550 – 720 MPa
Elongation (L=80mm) ≥ 16 %
Charpy Impact (at -20°C) ≥ 27 J
Hardness (typical) 160 – 200 HB
